Industrial Filament Sewing Yarn Doubling Twister Machine
DT2005 Precision CNC Composite Twisting Machine
industrial filament sewing yarn doubling twister machine
The finished yarn can reach the highest international quality standards and can be produced to some high value-added products. We can also undertake various kinds of processing business such as embroidery thread, knitting yarn, zipper, luggage lines etc according to clients’ requirement. If you need some kind of thread and yarns, not machine, you can also call us and tell us you requirements about thread or yarns and we will produce it in accordance with your demand.industrial filament sewing yarn doubling twister machine
High Quality Yarn
Winch roller driven by single spindle, more accurate yarn twist, no external force extrusion, more rounded cross section;
Display of computer tracking on spindle speed, ensure accuracy of both initial and compound twist;
No oil imported materials of high speed steel making, less breakage;
NC constant tension winding, ensure constant thread speed, volume weight up to 1.6kg.
Ply Count Range:
2×1: 50D—500D
3×1: 50D—1000D
Products apply for sewing, embroidery, bonded thread.
industrial filament sewing yarn doubling twister machine
Spindle arrangement | 2×1 | 3×1 | |
Supply spindle NO. (1section) | 36 | 40 | 36 |
Ring spindle NO. (1section) | 18 | 20 | 12 |
Supply spindle NO. (10section) | 360 | 400 | 360 |
Ring spindle NO. (10section) | 180 | 200 | 120 |
Main Technical Date:
Twist range | 650 to 1250t/m, 3 to 32t/inch |
Twist direction | S or Z changeable |
Assemble ends | 2-4 |
Ring | Φ115mm Φ140mm |
Max.winding height | 330mm |
Spindle driving | Tangential bel driving |
Start mode | Stepless speed controlled by inverter |
Take-up spindle gauge | 2×1 162mm 180mm 3×1 270mm |
Spindle speed | 6000-7500rpm |
Take-up bobbin capacity | 2×1 1.1kg 3×1 1.6kg or 2kg |
Max.installed power | 16.1kw |
Overall Size | L×W×H=18.84M×1.10M×1.80M |




Textile industry related information
industrial filament sewing yarn doubling twister machine
Nowadays, the integration of the two modernizations of the textile industry has bid farewell to the situation of fighting alone.
In 2018, the industrial Internet Alliance of China's textile industry was established. The establishment of the alliance will help promote the deep integration of the Internet and the textile industry, and help the textile and garment industry adapt to the new normal and achieve new development in response to industrial transformation and upgrading.
Zhai Yanju, director of Information Technology Department of China Textile Industry Federation, said that the alliance attaches great importance to promoting the construction and application of industrial Internet by undertaking key government projects. With the active efforts of the organization and member units of the alliance, the alliance units have undertaken a number of key projects supported by national and local governments, It has greatly promoted the development of industrial Internet. For example, in 2020, the project of "public service platform for application and promotion of digital transformation solutions in textile and garment industry" led by China Textile Information Center, the project of "industrial Internet application innovation and promotion center" led by Hongdou Group, the project of "characteristic regional industrial Internet platform test bed" led by Fuzhou University and the project led by Ruyi group Secondary node of industrial Internet logo analysis in garment industry, etc.
At the same time, the alliance also launched the "textile cloud classroom" through online means to carry out training and publicity on industrial Internet related technologies and applications in the textile industry. So far, the alliance has held 19 sessions; in 2019, the alliance held the discussion forum on the digital peak of Keqiao printing and dyeing enterprises In addition, the alliance also carried out research in the field of industrial Internet and organized the preparation of research reports and plans, mainly including the preparation of the Research Report on industrial Internet and textile industry; the Ministry of information technology of China Textile Federation and the first Institute of Electronics jointly prepared and released it Data map of integration of two modernizations in textile industry; organize several units in the alliance to prepare Research Report on integration of two modernizations and digital transformation of textile industry, etc.
Zhai Yanju said that in the future, the alliance will also organize the in-depth empowerment of industrial Internet platforms in the textile industry; continue to do a good job in the construction and application of key industrial Internet projects, support the application of new projects, organize exchanges and training on the cultivation and application of new technologies and models, organize the preparation of industrial Internet related research reports, and promote the implementation of industrial Internet in key industrial clusters Use.
Accelerating the digital transformation of manufacturing industry is an inevitable choice for China to seize the opportunity of a new round of scientific and technological revolution and industrial reform It is of great significance to make a good start. Cao Xuejun, a first-class inspector of the consumer goods department of the Ministry of industry and information technology, said that at present, the in-depth integration of the two modernizations is moving towards integrated innovation, Deepening Application and leading change. The textile industry should comply with the general trend of a new round of scientific and technological revolution and industrial change, based on the new development stage, closely follow the requirements of high-quality development, focus on quality and efficiency, and deepen the development of the Internet The innovative application of data and artificial intelligence in the industry, cultivate new driving forces for development, create a new ecology for development, and accelerate the digital transformation of the textile industry. We should focus on and promote the construction of industrial digital infrastructure, the digital transformation of enterprises, improve the construction of industrial Internet platform and strengthen the promotion of innovative application, so as to promote the development of information technology and the textile industry to a wider and deeper extent And a higher level of integrated development to improve the quality and comprehensive competitiveness of the textile industry.
